Moeller DILM17-10-24VDC xStart Contactor, and 50 similar items
Moeller DILM17-10-24VDC xStart Contactor, 460V 18A 24-27VDC Coil
$20.70
(It may be possible to pay only $18.01 instead of $20.70 when you
use your bCredits at checkout)
Sign up and get $5.00 bCredits free to use at checkout and another $5.00 bCredits when you make your first purchase. More info
Share & earn! Sign in, share this or any listing, and you’ll get commission when it sells.
Learn more
View full item details »
Shipping options
Offer policy
OBO - Seller accepts offers on this item.
Details
Return policy
Buyer must return the item within 30 days.
Buyer is responsible for any shipping costs associated with the return. Details
Purchase protection
Payment options
PayPal accepted
PayPal Credit accepted
Venmo accepted
PayPal, MasterCard, Visa, Discover, and American Express accepted
Maestro accepted
Amazon Pay accepted
Nuvei accepted
View full item details »
Shipping options
Offer policy
OBO - Seller accepts offers on this item.
Details
Return policy
Buyer must return the item within 30 days.
Buyer is responsible for any shipping costs associated with the return. Details
Purchase protection
Payment options
PayPal accepted
PayPal Credit accepted
Venmo accepted
PayPal, MasterCard, Visa, Discover, and American Express accepted
Maestro accepted
Amazon Pay accepted
Nuvei accepted
Item traits
| Category: | |
|---|---|
| Quantity Available: |
2 in stock |
| Condition: |
Used |
| MPN: |
DILM17-10-24VDC |
| Brand: |
Moeller |
| Number of Poles: |
3-Pole |
| Current Type: |
AC/DC |
| Type: |
Definite Purpose Contactor |
| Maximum Amperage: |
18 A |
| Current Rating: |
18 A |
| Country of Origin: |
Germany |
| Rated Operational Voltage: |
Up to 460 V AC |
| Rated Current: |
18 A |
| Control Coil Voltage: |
24-27 V DC |
| Horsepower Rating: |
5 HP at 230 V, 10 HP at 460 V |
| Auxiliary Contact: |
1 N/O |
| Connection Type: |
Screw terminals |
| Mounting: |
DIN rail or panel mount |
| Wire Size Range: |
AWG 14-10 (Cu 75 °C) |
| Tightening Torque: |
1.2 Nm (10.6 lb-in) |
| Impulse Withstand Voltage: |
6 kV |
| Operating Temperature: |
-25 °C to +60 °C |
Listing details
| Seller policies: | |
|---|---|
| Shipping discount: |
Shipping weights of all items added together for savings. |
| Posted for sale: |
More than a week ago |
| Item number: |
1786144937 |
Item description
Moeller DILM17-10-24VDC xStart Contactor, 460V 18A 24-27VDC Coil
Condition: Used
Dimensions: 5.00 x 5.00 x 5.00 inches (L x W x H)
Weight: 55.00 Lbs.
Compact 3-pole contactor for motor control applications, featuring a DC coil and auxiliary contact for reliable switching in industrial environments.
Manufacturer: Moeller (Eaton)
Model: DILM17-10-24VDC
Type: xStart Contactor
Rated Operational Voltage: Up to 460 V AC
Rated Current: 18 A
Number of Poles: 3
Control Coil Voltage: 24?27 V DC
Horsepower Rating: 5 HP at 230 V, 10 HP at 460 V
Auxiliary Contact: 1 N/O
Connection Type: Screw terminals
Mounting: DIN rail or panel mount
Wire Size Range: AWG 14?10 (Cu 75 C)
Tightening Torque: 1.2 Nm (10.6 lb-in)
Impulse Withstand Voltage: 6 kV
Operating Temperature: -25 C to 60 C
Dimensions: Approx. 90 mm (H) x 45 mm (W) x 85 mm (D)
Weight: Approx. 0.35 kg
Certifications: UL Listed, CSA, CE
Country of Manufacture: Germany
